Description
Heat Pump Rotary Enclosed Isolator 32 Amp 4-Pole with Cable Gland (IS-4P-32A-S-G)
Our CE-marked 4 pole rotary isolators is suitable for disconnecting power supply to outdoor air conditioning condensing units.. These isolators are IP65 waterproof, easy to install, and conform to IEC 60947-3 standards for safe and reliable operation.
Features:
- Weatherproof to IP65
- Easy installation
- M20/25 knockouts up to 63A
- Handle lockable in off position
- Interlocked cover – removable in off position only
- Earth and neutral terminals included
- Captive, retained cover screws
- Conforms to IEC 60947-3
- Comes with cable gland
Specifications:
| Part code | No of poles | AMPS AC21 | AC23 A 240VA | AC23 A 400VA | Cable capacity | Height | Width | Depth | |
|---|---|---|---|---|---|---|---|---|---|
| Solid | Stranded | ||||||||
| IS-4P-32A-S-G | 4 | 32 amp | 11kW | 7.5kW | 1-16mm² | 0.75-10mm² | 125mm | 100mm | 120mm |
