Description
ESBE GMA321 Separator Manifold for Pump Group (66000500)
Series GMA320 is manifolds for 2 circulation units and Series GMA330 is manifolds for 3 circulation units including insulation according to EnEV2014 and wall brackets.
Features:
- Insulation shell according to EnEV2014 standard
- Made for the circulation units DN20
- Easy installation with included wall brackets
Technical Specifications:
| Reference | GMA321 |
| No. of circulation units | 2 |
| Connections to system | RN 1″ |
| Connections from heat source | G 1″ |
| with hydraulic separator | No |
